Automatic Capsule Filling Machine
Automatic Capsule Filling Machine
Automatic capsule filling machine widely uses in pharmaceutical industry worldwide for preparation of solid dosage medicines in hard gelatin capsules. It has ability to fill powder, pellets and granules separately or in different combinations of powder & pallets in capsules. Adinath International is widely known as leading manufacturer, exporter and supplierof Automatic capsule filling machine in India. From last 22 years we have been serving domestic and international clientele with consistent quality and after sales support. Innovative products and lifetime spare parts support makes us the best choice among our valuable buyers. We have export presence in USA, Europe, Latin America, Middle East, South East Asia, Africa, Asia, India and served major pharmaceutical companies worldwide. Adinath International not only sells Automatic capsule fillers, but also provides excellent after-sales assistance whenever and wherever it is needed.
Specification of Automatic Capsule Filling Machine
The all-Automatic Capsule Filling Machine from Adinath International processes products for optimal productivity up to 90,000 capsules per hour, with low-maintenance operation, little downtime, and overall trustworthy output. For our pharmaceutical industry customers, we also develop High Speed Automatic Capsule Filling Machines with a manufacturing rate of up to 1,50,000 capsules per hour. For improved accuracy, the powder dosage is created with tamping pin technology. The machine is designed for excellent accuracy and can fill hard gelatin capsules in sizes ranging from 00 to 4.
The machine is controlled by a PLC with a user-friendly movable front end and a touch-enabled human interface.
Automatic Capsule Filling Machine Special Features
- Confirms to cGMP design standards with emphasis in powder dust handling.
- Enclosed dosing system with dust suction reduces cleaning frequency.
- Vacuum cleaning station for segment cleanup in each cycle.
- Efficient capsule separation by means of vacuum.
- Touch Screen HMI, featuring user friendly controls: production counter, manual / automatic / parameter setup modes, alarms.
- Precision capsule segments and dosing disk minimizes adjustments following parts changeover.
- Stainless Steel 304 frames and transparent safety interlock guards.
- Accurate capsule separation without damaging capsule with wide range of different capsules.
- Automatic rejection system for Non – separated/ improperly inserted capsule top Caps.
- Quick Fill weight adjustments and high precision dosing tools ensures optimum machine efficiency.
Technical Specification of Automatic Capsule Filler Machine:
| Sr.No. | Machine Model | ACF-25 | ACF-40 | ACF-70 | ACF-90 |
|---|---|---|---|---|---|
| 1 | Production Output / hr | 25,000 capsules | 40,000 capsules | 70,000 capsules | 90,000 capsules |
| 2 | Material of Construction: Contact parts Non-Contact parts |
SS 316 SS 304 |
SS 316 SS 304 |
SS 316 SS 304 |
SS 316 SS 304 |
| 3 | Power Supply | 3 Phase, 415 Volts, 50 Hertz |
3 Phase, 415 Volts, 50 Hertz |
3 Phase, 415 Volts, 50 Hertz |
3 Phase, 415 Volts, 50 Hertz |
| 4 | Compressor Air Required | 4 CFM | 4 CFM | 4 CFM | 4 CFM |
| 5 | Machine Dimensions Length (in mm) Width (in mm) Height (in mm) |
975 875 1955 |
975 875 1955 |
1300 1200 2300 |
1275 1200 2200 |
| 6 | Net Weight Approx (in Kgs.) | 850 | 850 | 1400 | 1600 |
How to Buy?
Contact our sales representative by phone or email to make an inquiry or purchase. We offer world-class customer service for all of our goods, including the Automatic capsule filling machine. We provide a single window clearing system for international buyers, where we appoint a dedicated account manager to you for all of your Automatic Capsule Filler needs. All required documentation and industry-specific specifications are handled by us. Please do not hesitate to contact us if you require a product catalogue or pricing information.
